AUTOMATIC CELL COUNTER AND CELL VIABILITY ANALYZER

NORMA XS

The easiest solution for accurate and precise viable cell count

For research use only (RUO). Not for use in diagnostic procedures.

NORMA XS CELL ANALYSIS CELL COMPTING CELL VIABILITY
Sample Icon

SAMPLE PREPARATION FREE

Short Time

SHORT TIME RESULTS

High Repet

HIGH REPEATABILITY

Low Volume

LOW SAMPLE VOLUME

check norma

MATCH WITH REFERENCE TRYPAN BLUE METHOD

THE SIMPLEST BENCHTOP CELL COUNTER

The NORMA XS, based on the new lens-less technology, is the simplest automatic benchtop cell counter for cell culture monitoring. It rapidly measures cell concentration and viability without repeatability compromise. The NORMA XS provides an unmatched accuracy and precision thanks to its wide field of view (29.4 mm2) that allows counting several thousand of cells within a single sample image! No need to adjust focus, brightness or any other parameters, our algorithm will reconstruct cells wherever cells are located… from a few micrometres to some millimetres! There is no sample preparation: no dilution and no Trypan Blue! You just have to take about 3µL of your sample and to deposit it on the measuring slide. These characteristics make the NORMA XS an extremely robust device not fearing temperature variation or any other parameter which can affect traditional focus adjustment.

NORMA XS Compteur cellulaire

FEATURES OF THE NORMA XS

  • Tiny device
  • In direct from your incubator
  • Time-Lapse & Movie
  • Many cell cultures application
  • Robust
  • High Contrast
  • Always in focus
  • Wide field of view
check norma

AUTOMATIC CELL COUNT

VIABILITY

CELL SIZE DISTRIBUTION

RATIO ASPECTS

GROWTH CURVES

HOW TO USE IT ?

The NORMA XS is very easy to use !

NORMA XS pipette extraction

Take your unprepared sample.
(LABEL FREE, UNDILUTED)

NORMA XS pipette

Load the sample into the slide chamber.

Norma XS Instrument Comptage et Analyse de la Viabilité Cellualire

Insert the slide into the NORMA XS and press measure.

Horus Software for cell viability analyzer NORMA

WHAT ARE THE RESULTS ?

Then, the technology directly acquires the light diffraction properties of each individual cells through their hologram images without any settings. Several thousands of holograms are acquired into one single image that is immediately “reconstructed” with our HORUS holographic algorithm to obtain a microscopic like picture; at this stage cells can be segmented. Living and dead cells have significant holographic patterns that can be distinguished and accurately count.

The measurement results are returned by the HORUS software. Each parameter is visible on a simple graphical interface with the possibility to follow several running cultures on user friendly charts.

A STRONG CORRELATION WITH THE TRADITIONAL TRYPAN BLUE METHODS

Comparatives studies between the NORMA XS and other traditional counters have been performed and have shown their strong correlation and the High Repeatability of the NORMA XS!

NORMA XS cells
Iprasense Horus Software Cell Culture Monitoring and your Cell Viability

HORUS Software Included

Our best software for cell counting and cell analysis !

HORUS Software is included with the acquisition of our products and is regularly updated by our development team.

TECHNICAL SPECIFICATIONS

Cells
Eucaryotic cells: adherent monolayer, suspension cell at bottom of culture ware or in micro-slides, 3D sheroids
Media
Liquid or semi-liquid (collagen)
Culture contains
Standard plastic petric dishes, culture flasks, multiwell plates, max height 55 mm
Resolution
1 micron
Field of view
29.4 mm²
Working distance
0 to 5 mm
Image rate
1.5 image/min
Light source
LED
Sensor
CMOS 10 Mpixels
Weight
1 kg
Dimensions
12 * 11 * 10 cm
Power supply
USB

ACCESSORIES AND CONSUMABLES

HORUS Software
21 CFR
Scratch Assay analysis module for HORUS Software
Cell Tracking analysis module for HORUS Software
Cell Tube Formation analysis module for HORUS Software
Cytonote cable – 2 meters
Laptop computer
IQ/OQ

F.A.Q.

The NORMA range allows you to count your cells and determine their viability and diameter. You will get automatically saved images.

No, only your raw sample is needed in order to do the cell count and viability analysis.

Yes, all our products are driven directly by our HORUS software. The data is also analysed by it.

Yes, all our products are 21 CFR.

By default, the image format is JPEG. It is possible to have images in PNG, BITMAP, TIFF. The results can be exported in CSV, XML, XLSX format.
